Detail Vibration Meter TV310 & TV320
Features:
? TV310 is equipped with low sensitivity probe, suitable for testing strong vibration signal.
? TV320 is equipped with high sensitivity probe, suitable for testing weak vibration signal.
? Two display modes: digital value mode and spectrum mode
? Large memory function: 100 100 measured results( 100 testing points, 100 data can be stored in each testing points ) ; 100 Spectral chart
? Spectrum chart can display in real time
? Easy diagnosis: alarm is sounded when vibration go over limit set , and get into spectrum mode
? Testing results and spectrum chart can be printed out when connected to printer
? 300 200 matrix LCD display, with backlight
? Compared with TV300, the testing result of TV310/ 320 is more accurate and stable especially in low frequency
Model TV310 TV320
Measuring range Acceleration: 1m/ s2~ 392 m/ s2 ( Peak) Acceleration: 0.1m/ s2~ 20 m/ s2 ( Peak)
Velocity: 0.1cm/ s~ 80cm/ s ( RMS) Velocity: 0.01cm/ s~ 4cm/ s ( RMS)
Displacement: 0.01mm~ 18.1mm ( Peak-Peak) Displacement: 0.001mm~ 0.8mm ( Peak-Peak)
Frequency range Accelertation: 10Hz~ 200Hz, 10Hz~ 500Hz, 10Hz~ 1KHz, 10Hz~ 10KHz
Velocity: 10Hz ~ 200Hz, 10Hz~ 500Hz, 10Hz~ 1KHz
Displacement: 10Hz~ 500Hz
Accuracy 5%
Temperature 0 ~ 40
Relative humidity d80%
Dimension 171 78.5 28 ( mm)
Power Li battery ( continuous working 20 hours)
Standard Packing Main unit, Protection pocket, Low sensitivity probe ( TV310) , High sensitivity probe ( TV320) , Power adapter, Magnetic base, Instruction manual, Software, Cable
Optional Parts Needle Groupware, Printer TA230
